This is the switched-mode power supply (SMPS) which convert 100-250V AC to 12V DC. It can provide up to 30A maximum current. All types of protections are provided in the supply. This power supply is built has a built-in fan on/off control circuit. The Fan automatically works according to the working temperature.
SPECIFICATIONS
| Input Voltage | 100V-250V AC 50 / 60Hz |
| Output Voltage | 12V DC, 30A |
| Protections | Output Over Voltage Protection, Over-Current Protection, Short Circuit Protection, Surge Protected Outputs |
| Dimensions (LxWxH) | 210x115x50 (mm) |
| Weight | 700 gm |
| Country of Origin | China |
Features:
- Output Over Voltage Protection, Over Current Protection, Short Circuit Protection and Surge Protected output are provided.
- Universal AC Range
- Metal Case is provided
- No Minimum load is required
- High Efficiency, Reliability & low energy consumption
- This power supply is built has built-in fan on/off control circuit. The Fan automatically works according to the working temperature.
