DC 12V Large Torque 775 Motor

Specifications:

• Model: 775
• Shaft Diameter: 5mm
• Shaft Length: 14mm
• Body Length: 66.7mm
• Front Steps Diameter: 17.4 mm
• Body Diameter: 42 mm
• Motor Overall Length: 98 mm
• Mounting Hole Location Diamater: 28.8 mm
• Mounting Hole Size: M4
• Mounting Hole: 2
• Torque: 2kg.cm or 0.2N.M
• Working voltage: 12-24V
• Idling speed: 13000~15000rpm
• Rated current: 6.25A at 12V
• Rated power: 150W at 12V
