Simon 30A ESC

Simonk 30AMP is Best 30a ESC Brushless Motor Speed Controller specifically made for quadcopters and multi-rotors.

it provides faster and better motor speed control giving better flight performance compared to other available ESCs.

30a brushless motor esc can drive motors which consume current up to 30A. It works on 2S-3S LiPo batteries.

This electronic speed controller offers a battery eliminator circuit (BEC) that provides 5V and 2A to the receiver so we don’t need extra receiver battery.

This version of the ESC 30a also includes backwards-polarity protection and protection on the 5V receiver line, this means that if you accidentally attach a battery backward it won’t destroy your motor controller and other BECs won’t affect the ESC.

A 30a brushless esc or an Electronic Speed Controller controls the brushless motor movement or speed by activating the appropriate MOSFETs to create the rotating magnetic field so that the motor rotates.

The higher the frequency or the quicker the ESC goes through the 6 intervals, the higher the speed of the motor will be.

The simonk esc has two wires coming from a battery, and then two wires going to the DC brushed motor. These can be any voltage that maximizes the motor’s revolutions per minute (RPM).

SimonK esc30a firmware is a firmware specifically for ESCs (electronic speed controllers) developed by Simon Kirby.

This firmware has been found to offer faster response compared to normal ESC firmware, easy handling and good compatibility, all of which greatly enhances multirotor performance.

Features: –

• Designed for QAV180 210 250 ZMR250 Quadcopter.
• Low-voltage protection, over-heat protection, and self-check functions.
• Separate power supply for MCU and BEC.
• Enhancing the ESC’s ability to eliminate magnetic interference.
• Parameters of the ESC can be set via a program card or transmitter.
• Throttle range can be set to compatible with different receivers.
• Equipped with built-in BEC.

30a ESC Brushless Motor Speed Controller Specifications:

• Current: 30A
• Burst Current: 35A
• BEC Model: Linear mode
• BEC Output: 5V2A
• Li-ion/Li0poly:2-4S,or Ni-MH/Ni-Cd:4-12NIMH
• Weight: 25g
• Size: 32*24*7mm

These ESC are normally powered by a 2S or 3S Lipo battery and can supply around 30A maximum. It also has an in-built BEC which provides a regulated 5V with a current rating of 2A (maximum) that could be used to power the flight controller and other controllers associated with the Drone.
