ACR122U Technical Specifications
Dimensions
98.0 mm (L) x 65.0 mm (W) x 12.8 mm (H)
Weight
70.0 g
Compliance / Certifications
- ISO 18092, ISO 14443, PC/SC, CCID, EN60950/ISO 60950, CE, FCC, MIC, KC, VCCI, RoHS 2, USB Full Speed, Microsoft® WHQL
Interface
USB Full Speed
Operating Distance
Up to 50 mm (depends on the tag type)
Supply Voltage
Regulated 5V DC
Supply Current
200mA (operating); 50mA (standby); 100mA (normal)
Operating Temperature
0-60 °C
Operating Frequency
13.56 MHz
Smart Card Interface Support
- ISO14443 Type A & B
- MIFARE
- FeliCa
- 4 types of NFC (ISO/IEC18092) tags
Operating System Support
- Windows®
- Win CE 5.0 and 6.0
- Linux®
- Mac OS®
- Android™ 3.1 and above
