LM2596 3A Step Down Voltage Switching Regulator
₨ 50.00
In stock
16
People watching this product now!
Description
The LM2596 is a commonly used popular step-down switching regulator IC. The adjustable version can take in input voltage from 4.5V to 40V and convert it to variable voltage sourcing upto of 3A of continues current. Because of its high current capability is commonly used in power modules to power/control heavy loads.
Pin Description
|
Pin Number |
Pin Name |
Description |
|
1 |
V-IN |
Input voltage that is to be regulated |
|
2 |
V-OUT |
Stepped down Regulated output Voltage |
|
3 |
Ground |
Connected to system ground |
|
4 |
Feedback |
Sets the output voltage using divider network using output voltage feedback |
|
5 |
ON/OFF |
Enable pin, should be grounded for normal operation |
Features
- 3A Step Down Voltage Regulator IC
- Available as 3.3V regulator, 5V Regulator, 12V Regulator and Variable regulator
- Input Supply Voltage: 4.5V to 40V
- Minimum Output Voltage: 3.16V
- Continuous Output Current: 3A
- Peak Output Current: 6.9A
- Switching Frequency: 150KHz
