5S 15A Lithium Battery BMS Protection Board with Balance Function

SKU: 0358
19 People watching this product now!

₨ 400.00

In stock

In stock

Description

The 5S 15A Lithium Battery BMS Protection Board with Balance Function is designed to provide essential protection and cell balancing for compatible 5-series lithium battery packs. This battery management system (BMS) helps protect the battery against common electrical faults, including overcharging, over-discharging, overcurrent, and short circuits, depending on the board’s protection design.

Suitable for DIY battery packs, portable electronics, LED lighting systems, and other compatible battery-powered applications, this 5S 15A BMS board supports safer battery operation while helping maintain balanced voltage levels across individual cells.

Its compact design makes it a practical choice for battery pack assembly, repair, and replacement projects where reliable battery protection and cell balancing are required.

Key Features

  • 5S Battery Compatibility: Designed for battery packs containing five cells or cell groups connected in series.
  • 15A Current Rating: Supports a rated current of up to 15A, subject to the manufacturer’s specifications and cooling requirements.
  • Cell Balancing Function: Helps equalize the voltage of individual series-connected cells during charging.
  • Overcharge Protection: Helps prevent individual cells from exceeding their specified charging voltage.
  • Over-Discharge Protection: Helps prevent battery cells from discharging below their permitted voltage.
  • Overcurrent Protection: Helps protect the battery pack against excessive current draw.
  • Short-Circuit Protection: Provides protection against short-circuit conditions when supported by the board’s design.
  • Compact PCB Design: Suitable for integration into compatible battery packs and electronic projects.

Technical Specifications

Specification Details
Product Name 5S 15A Lithium Battery BMS Protection Board
Product Type Battery Management System (BMS)
Battery Configuration 5S (5 cells or cell groups in series)
Rated Current 15A
Battery Chemistry Lithium-ion; verify compatibility with the specific board
Nominal Battery Voltage 18V nominal for a typical 5S lithium-ion pack
Full-Charge Voltage Typically 21V for a 5S lithium-ion pack using 4.2V-per-cell charging
Cell Balancing Yes
Overcharge Protection Supported, subject to board design
Over-Discharge Protection Supported, subject to board design
Overcurrent Protection Supported, subject to board design
Short-Circuit Protection Supported, subject to board design
PCB Type Electronic protection circuit board
Application Lithium battery pack protection and balancing

Note: Protection thresholds, balancing current, dimensions, connector type, continuous discharge rating, and charging current should be confirmed against the actual product datasheet. A 5S LiFePO4 battery pack has different voltage requirements and must use a BMS specifically designed for LiFePO4 chemistry.

Applications

The 5S 15A Lithium Battery BMS Protection Board can be used in compatible battery-powered products and projects, including:

  • DIY lithium-ion battery packs
  • Portable electronic devices
  • LED lighting and emergency lighting systems
  • Small battery-powered equipment
  • Electronic repair and battery replacement projects
  • Custom rechargeable battery assemblies
  • Other applications requiring a compatible 5S battery protection circuit

Why Choose a 5S 15A BMS Protection Board?

A battery management system is an important component of a rechargeable lithium battery pack. It helps monitor and protect the battery against specified electrical faults and supports more consistent cell voltages through balancing.

The 5S 15A Lithium Battery BMS Protection Board combines battery protection and balancing functionality in one compact circuit board. It is a practical solution for users building or maintaining compatible five-series lithium battery packs.

For best performance, select a BMS that matches the battery chemistry, charging voltage, discharge current, and intended application.

Installation and Safety Guidelines

  1. Confirm that the battery pack contains five series-connected cells or cell groups.
  2. Verify that the BMS is compatible with the battery chemistry and cell voltage limits.
  3. Connect the battery terminals and cell-sensing wires according to the manufacturer’s wiring diagram.
  4. Use a compatible charger with the correct charging voltage and current limits.
  5. Ensure the board’s current rating is suitable for the actual load and operating temperature.
  6. Avoid reverse polarity, incorrect wiring, and short circuits during installation.

Installation should be performed by a person familiar with lithium battery systems. A BMS does not replace a suitable charger, correct cell selection, proper insulation, or other necessary battery safety measures.
