Seeed Studio XIAO ESP32C6
₨ 2,000.00
In stock
In stock
Description
The Seeed Studio XIAO ESP32C6 is an ultra-compact and high-performance development board powered by the Espressif ESP32-C6 microcontroller. Designed for next-generation IoT applications, it supports Wi-Fi 6 (802.11ax), Bluetooth 5.3 LE, Zigbee, Thread, and Matter, making it an excellent choice for smart home devices, wireless sensors, industrial automation, and embedded systems.
With its tiny 21 × 17.8 mm form factor, USB Type-C connectivity, low-power operation, and rich GPIO capabilities, the XIAO ESP32C6 delivers exceptional performance for developers, makers, students, and professionals.
Key Features
- Powered by Espressif ESP32-C6 SoC
- Dual 32-bit RISC-V processors
- High-performance CPU up to 160 MHz
- Low-power RISC-V processor up to 20 MHz
- Built-in Wi-Fi 6 (2.4 GHz)
- Bluetooth 5.3 Low Energy
- Native Zigbee and Thread support
- Matter-ready smart home platform
- 512 KB SRAM
- 4 MB Flash Memory
- Ultra-low power operation for battery-powered devices
- USB Type-C programming interface
- Compact 21 × 17.8 mm XIAO form factor
- Compatible with Arduino IDE, ESP-IDF, MicroPython, and PlatformIO
Technical Specifications
| Specification | Details |
|---|---|
| Microcontroller | Espressif ESP32-C6 |
| CPU | Dual 32-bit RISC-V |
| Main CPU Speed | Up to 160 MHz |
| Low Power CPU | Up to 20 MHz |
| SRAM | 512 KB |
| Flash Memory | 4 MB |
| Wireless | Wi-Fi 6 (802.11ax) |
| Bluetooth | Bluetooth 5.3 LE |
| IEEE 802.15.4 | Supported |
| Zigbee | Yes |
| Thread | Yes |
| Matter | Native Support |
| GPIO | 11 GPIO Pins |
| ADC | 7 Channels |
| UART | 1 UART + 1 LP_UART |
| I2C | 1 I2C + 1 LP_I2C |
| SPI | 1 SPI |
| SDIO | Supported |
| USB | USB Type-C |
| Operating Voltage | 3.3V |
| Input Voltage | 5V (USB Type-C) |
| Board Size | 21 × 17.8 mm |
| Operating Temperature | -40°C to 85°C |
Why Choose the XIAO ESP32C6?
The Seeed Studio XIAO ESP32C6 is one of the first compact development boards featuring the latest ESP32-C6 chipset with native support for Matter, Thread, and Wi-Fi 6.
Compared to previous ESP32 boards, it offers:
- Faster wireless communication
- Improved network efficiency
- Better power management
- Enhanced IoT security
- Future-ready smart home compatibility
- Extremely compact footprint
Whether you’re building a smart sensor, wearable, home automation controller, or industrial IoT device, the XIAO ESP32C6 provides powerful performance in a miniature package.
Applications
- Smart Home Automation
- Matter Devices
- IoT Gateways
- Zigbee Projects
- Thread Networks
- Environmental Monitoring
- Wireless Sensor Nodes
- Home Assistant Devices
- Wearable Electronics
- Industrial Automation
- Robotics
- Data Logging
- Remote Monitoring Systems
- Educational Projects
- DIY Electronics
Package Includes
- 1 × Seeed Studio XIAO ESP32C6 Development Board
Software Support
The XIAO ESP32C6 is compatible with:
- Arduino IDE
- ESP-IDF
- PlatformIO
- MicroPython
- ESP RainMaker
- AWS IoT
- Microsoft Azure IoT
- Google Cloud IoT
Advantages
- Tiny and lightweight design
- Excellent wireless performance
- Future-proof Matter support
- Low power consumption
- Easy USB-C programming
- Reliable ESP32 ecosystem
- Extensive community support
- Ideal for professional and hobby projects
