Home Module Sensor Module Vending Machine Coin Acceptor
Eye Blink Sensor ₨ 800.00 ₨ 760.00
Back to products
Glue Gun Mini 20W ₨ 250.00 ₨ 237.50

Vending Machine Coin Acceptor

₨ 2,000.00 ₨ 1,900.00

In stock

Add to wishlist

Choose a wishlist or Create a new list

Add to wishlist
Compare
Compare
17 People watching this product now!
SKU: 0769 Categories: Module, Sensor Module

Share this:

  • Click to share on Twitter (Opens in new window)
  • Click to share on Facebook (Opens in new window)
Share:
  • Description
  • Additional information
  • Shipping & Delivery
Description

GDY007 – Intelligent Coin Acceptor Module

1 coin acceptance, handle different countrys coins, pulse output signal,12v input. This product is known as Multi Coin Acceptor Programable for Vending Machines, Coin Machine, Multi Coin Acceptor Vending Machine, Vending Machine Coin Acceptor, Coin Programmable Coin Acceptor Module for Vending Machine, 1 coin acceptance, coin acceptance, intelligent coin acceptor Module, single-coin intelligent vending machine coin.

GD 007 Intelligent Coin Acceptor Product Brief Introduction

  • Acceptance: One Coins Only. Press program coin button 3 sec. Program 1 coin 30 times.
  • Supply voltage:DC+12V discrepancy 20%,quiescent current less than 40mA,dynamic current less than 400mA.
  • Output Mode: Audion Open-collector output
  • Supply Voltage: DC+12V discrepancy 20%
  • Temperature: -10Celsius degree ~ +60Celsius degree

Features:

  • Sample coin comparison type validator
  • Programmable for one coin type based on coin material. thickness and size
  • Quick-release face plate for easy maintenance
  • Black color face plate with push button type coin release

Features/Specs:

  • GD 007 Single-coin intelligent validator
  • Operating Voltage: 12VDC discrepancy 20%
  • Temperature:-10 ~ +50°C
  • Coin Diameter:10.8mm To 31mm
  • Coin Thickness: 1.2 To 3 mm

Application:

  • Vending Machine

Datasheet: GDY007 – Intelligent Coin Acceptor Module

Package Includes:

  • 1 x GDY007 – Intelligent Coin Acceptor Module

Note: Product Images are shown for illustrative purposes only and may differ from the actual product.

Additional information
Weight 0.00 kg
