Specifications
| Attribute | Value |
| Display Type | 7-Segment |
| Number of Characters | 4 |
| LED Colours | Green |
| Number of Segments | 7 |
| Dominant Wavelength | 573 nm |
| Character Width | 6mm |
| Character Height | 10mm |
| Common Connection | Cathode |
| Mounting Type | Through Hole |
| External Width | 40.2mm |
| External Height | 7mm |
| External Dimensions | 40.2 x 12.8 x 7mm |
| External Depth | 12.8mm |
| Luminous Intensity | 4 mcd |
| Colour of Face | Grey |
| Power Dissipation | 60mW |
| Forward Voltage | 2 V |
| Minimum Operating Temperature | -40°C |
| Decimal Orientation | Right Side |
| Operating Temperature Range | -40 → +85°C |
| Maximum Operating Temperature | +85°C |
| Forward Current | 25mA |
