CP2102 module USB to TTL serial UART

Features:

• Communication format support: 5,6,7,8 bits of data; support 1,1.5, 2 stop bits.; odd, even, mark, space, none
• The USB head for the head can be directly connected to the computer USB port
• The main chip CP2102, generates a virtual serial port after installing the driver, Taking power, USB, and elicit interface includes 3.3 V (< 40 ma), 5 V, GND, TX and RX, signal feet is 3.3 V, is logical
• Send and receive, onboard status indicator lights, lights, right after installing the driver state will Chang Liang lights, a transceiver indicator light will flash when communication, the lower the baud rate, the higher the brightness
• Provides connection from USB on the host computer to microcomputers or other TTL signal level accessories
