Ultra-Small Lithium Battery Charging Panel 1A Ternary Lithium Battery

SKU: 0256

 100.00  98.00

Out of stock

Out of stock

14 People watching this product now!


1.Small size
2.Support Type-C interface power supply, compatible with most PD fast charging heads
3.1A high current linear charging
4.With protection board function

Input voltage range: 5~6V
Output voltage: 4.2V
Charging current: 1A

Function introduction:
1. When the charging current drops to 100mA after reaching the final float voltage, the charging cycle will be automatically terminated.
2. When the battery voltage drops below 4.05V (roughly corresponding to 80% to 90% of the battery capacity), the charging cycle restarts.
3. When the battery voltage is lower than 2.9V, the battery will be precharged with a current of 100mA.
4. With protection board, over-voltage protection, over-discharge protection, over-current protection. Over-discharge protection value: 2.4V; over-current protection value: 4A.
5. For the first use, you need to connect the power supply to activate the protection board.
