Serial Board Module Port IIC/I2C/TWI/SPI Interface Module 1602 LCD Display

SKU: 0104

 200.00

In stock

In stock

11 People watching this product now!

Description

Description:

This is a I2C Serial LCD Daughter board that can be connected to a standard 16×2 or 20×4 Character Display Module that supports 4-bit mode. All Character Modules sold on our site support 4-bit mode, and nearly all commercially available 16×2 and 20×4 line character modules support it too. This board has a PCF8574 I2C chip that converts I2C serial data to parallel data for the LCD display. There are many examples on the internet for using this board with Arduino. Do a search for “Arduino LCD PCF8574“. The I2C address is 0x3F by default, but this can be changed via 3 solder jumpers provided on the board. This allows up to 3 LCD displays to be controlled via a single I2C bus (giving each one it’s own address).

Specification:

  • IC Chip: PCF8574
  • Power Supply: 5V

Features:

  • 16 x 2 Character LCD display is controlled via just two wires
  • Up to 8 LCD displays with adapters can be connected and controlled by the same two wire I2C bus
  • Easy to control using Arduino board
  • Compatible with 16 x 2 character LCD displays
  • Adapter includes 16-PIN male header connector for soldering to LCD display
  • Contrast is adjusted via onboard potentiometer
  • Backlight may be turned on/off via jumper
  • Standard 5V voltage supply

Package Included:

1 x IIC I2C TWI SPI Serial Interface Board Module Port for Arduino LCD1602 Display
